Prolink UPS PRO910-ES 10kVA/9,000W Standar
Rp48.281.250
Prolink UPS PRO810-QS 10kVA/10KW Standar
Rp59.800.000
Prolink UPS PRO803-QS 3kVA/3KW Standar
Rp19.280.000
Deskripsi
Spesifikasi
| Tipe UPS | Online, true double-conversion |
| Kapasitas | 3000 VA / 3000 W |
| Input (AC) | 1 Phase with ground |
| DC Output (nominal) | 3000 W (power factor 1.0) |
| Input Voltage Range | 110–300 VAC @ 50% load; 160–300 VAC @ 100% load |
| Input Power Factor | ≥ 0.99 @ nominal voltage |
| THDi Input | ≤ 5 % |
| Output Voltage Regulation | ±1 % (Battery Mode) |
| Output Frequency | 47–53 Hz synced / 50 Hz ±0.1 Hz (Battery Mode) |
| Transfer Time | 0 ms (AC→DC) / 4 ms (Inverter→Bypass) / 8–10 ms (ECO→Battery) |
| Waveform (Battery Mode) | Pure sinewave |
| Kapasitas Battery | 6 × 12 V / 9 Ah |
| Waktu Isi Ulang | ~3 jam ke 95 % @ 2A charging current |
| Efisiensi | Line Mode ≥ 91 %; ECO Mode ≥ 96 %; Battery ≥ 90 % |
| Display & Alarm | LCD + LED indikator status, alarm suara sesuai keadaan (battery/load/overload/fault) |
| Antarmuka Komunikasi | RS-232, USB, Emergency Power Off (EPO); opsional SNMP slot |
| Dimensi | 421 × 190 × 318 mm |
| Berat | ≈ 28 kg |
| Level Kebisingan | < 50 dBA @ 1 m |
