VTH1020J |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Button Type |
Mechanical |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Basic |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Display |
7.0″ TFT |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Screen Resolution |
1024 × 600 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Status Indicator |
1 indicator light |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Function |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Communication Mode |
Analog |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Casing |
PC + ABS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Color |
White |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Power Supply |
DC 12V/2A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Power Adapter |
Included |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Installation |
Surface mount |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Certifications |
CE/FCC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Accessory |
Bracket (included) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Dimensions |
133.90 mm × 182.70 mm × 17.70 mm (5.27″ × 7.19″ × 0.70″) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Temperature |
-10°C to +55°C (+14°F to +131°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Humidity |
10%RH–95%RH |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Power Consumption |
≤ 2W (standby) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Net Weight |
0.25 kg (0.55 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Gross Weight |
0.48 kg (1.05 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VTO1000J |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Button Type |
Mechanical |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Basic |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Camera |
1.3MP CMOS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Field of View |
Horizontal: 70° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
WDR |
DWDR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Illuminator Type |
Auto IR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Day/Night |
ICR auto switch |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Audio Input |
1 channel to the microphone; pickup distance 0.5 m |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Audio Output |
1 channel to the speaker |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Status Indicator |
1 indicator light |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Function |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Communication Mode |
Analog |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Unlock Mode |
Local unlock |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Casing |
PC + ABS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Exit Button |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Door Status Detection |
1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Color |
Silver |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Power Supply |
Powered by indoor monitor |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Installation |
Surface mount |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Certifications |
CE/FCC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Accessory |
Rain cover (included) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Dimensions |
131.45 mm × 46.00 mm × 33.80 mm (5.18″ × 1.81″ × 1.33″) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Protection Grade |
IP66 (Apply silicon sealant to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Temperature |
-30°C to +60°C (-22°F to +140°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Humidity |
10%RH–95%RH |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Power Consumption |
≤ 1W (standby) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Net Weight |
0.18 kg (0.40 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Gross Weight |
0.38 kg (0.84 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
